Flat Lock
The Flat Lock panel system is a hook seam system that is wind resistant in a shingle-style panel. This system offers more relief in the reveals, giving it the ability to create shadows. The angled position of the panels allows light to reflect at various angles, ideal for finishes with depth. Additionally, panels may be micro-perforated and have backing added to transform them into acoustic panels.
See the full system performance, details, options, and downloadable files below.
About Pure + FreeForm Flat Lock Wall System
How to Specify Flat Lock System
Select a Finish
Select from one of our bold, extraordinary, design-forward finishes or choose to create a custom finish. See all of our finishes to find which is perfect for your design.
Choose a Standard Size
Flat Lock panels come in both standard and custom sizing. Standard widths are 12″ – 16″ with standard lengths 36″ – 60″ in both horizontal and vertical applications. Panels are available in thicknesses from 0.8mm to 1.0mm.
All of our systems can be customized. Standard sizes will be the most cost-effective option.
Standard Sizes
12″ x 36″
12″ x 48″
12″ x 58″
16″ x 36″
16″ x 48″
16″ x 58″
Choose A Joint Orientation: Staggered or Aligned
Panels can have the vertical joint lines aligned, or in a Stack formation, or staggered, in a Running Bond formation. No matter the design, the fasteners for this system are concealed.
Add Perforations or Acoustics
These panels can be perforated or have acoustical backing added to them, or both! Perforation patterns can be custom or standard, see our offerings.
